Hybrid lifting station

Ecolift L

The direct route to sustainable building.

The Ecolift principle

Pumps only when it needs to!

In many installation situations – in both commercial and residential buildings – there is a natural gradient to the sewer. Here too, a lifting station is usually installed as a result of the standard, although the drainage could take place without the use of expensive energy. We have rethought wastewater disposal in the case of natural gradients – and combined the lifting station with the advantages of a backwater valve.

The Ecolift principle uses gravity to drain water without any power consumption. The hybrid lifting station begins to dispose of the wastewater with the use of a pump, only in the vent of backwater, so that the connected drainage elements can continue to be used. At the same time, the integrated closure device prevents the ingress of water from the sewer into the building.

Sustainable

Pump operation only in the event of backwater

The Ecolift L takes advantage of gravity: Due to the natural gradient, it diverts wastewater without consuming electricity. It uses the pumps for wastewater disposal only in the event of backwater. This saves energy and at the same time protects the environment. Perfect for energy-related renovations!

Reliable

Reliable protection in the event of backwater

The Ecolift L combines the best of both worlds as a lifting station and backwater protection. Good to know: The integrated backwater valve remains functional even in the event of a power failure thanks to the battery backup. This guarantees continuous operation at all times. A self-cleaning effect ensures the permanent removal of dirt. And the integrated self-diagnosis system (SDS) provides information about the current operating state of the system.

Cost-saving

Economical to operate

The system is assembled plug-in ready so the installation is simple and quick and no specialist is required for the connection. The ongoing operating costs are low because the pump only runs in the event of backwater. In contrast to a conventional lifting station, maintenance on a hybrid lifting station only needs to be carried out half as often in a commercial operation. And the reduced wear significantly increases its longevity. All this makes the Ecolift L an economical alternative for new buildings and renovations.

Discover the savings potential!

We are pleased to show you, using a concrete example, how high the savings potential is with an Ecolift L compared to a classic lifting station. The comparison is based on the total wastewater from the toilet facilities of a railway station with 20 toilets, 6 urinals, 4 showers and 6 washbasins (underground installation, maintenance costs incl. travel, average values).

Comfortable

Easy to use

Assembled plug-in ready, quick to install. Practical shut-off valve. Optional wall bracket for easy access to the hybrid lifting station: The Ecolift L provides extra comfort with its features. However, this applies not only for its installation, but also for its operation. Since the pump only works in the event of backwater, the hybrid lifting station is ultra-quiet when it is running. And the dry set-up of the pumps makes maintenance a clean affair.

Compact

Space-saving installation

Particular attention must be paid to the existing structural conditions, especially in the case of energy-related renovations. The Ecolift L for free-standing set-up impresses not only with its compact size, but also with its flexibility.

Flexible

One or two pumps

A Mono version with a single pump is usually sufficient for private use. However, if it is a commercial property or an apartment building, then uninterrupted operation must be guaranteed at all times. In this case, the Ecolift L is available as a Duo system with two pumps. The highlight of this hybrid lifting station: a second pump can also be retrofitted.

Application possibilities

Reduced costs, less power consumption, less wear: The savings potential of an Ecolift L is impressive on many levels. And the best thing, it is suitable for a wide range of applications. Here are a few examples:

Appartment buildings

The Ecolift L (FKA) can also be installed with a pressure loop in an apartment building whose ground floor is located below the backwater level.

Bypass system

Exclusive only with KESSEL: The clever bypass system of the Ecolift L Bypass (FKA) pumps the wastewater from an apartment building past the backwater protection into the drainage pipe.

Commercial buildings

Performance for the commercial sector: The Ecolift L Bypass (SWA) can also be installed in commercial buildings downstream of a separator system without any problems.

Product recommendation

Five questions – one smart solution

Question 1: Is there a natural slope to the sewer?

Question 2: What type of building is it?

Question 3: Is black water discharged?

Question 4: Is a backwater loop required?

Question 5: What is the maximum wastewater discharge based on the equipment draining into the hybrid lifting station?

Need help?

Contact us!

Lifting stations

For use inside buildings

Ecolift

Hybrid lifting station

Ecolift XL

Hybrid lifting station

Pumpfix F

Backwater pumping station

Ecolift L Mono

Art. no. 22000

Ecolift L Duo

Art. no. 22001

Ecolift L Mono

Art. no. 22002

Ecolift L Duo

Art. no. 22003

Ecolift L Bypass Mono

Art. no. 22004

Ecolift L Bypass Duo

Art. no. 22005

Ecolift L Bypass Mono

Art. no. 22006

Ecolift L Bypass Duo

Art. no. 22007

Combined know-how

Documents to download

The most important information combined in one format: Download the product brochure now with all the relevant information about the Ecolift L hybrid lifting station.

Product brochure

Manual

Ecolift

The clever version for private use:
The Ecolift is the ideal and cost-effective drainage solution for natural gradients.

Ecolift L

The high-performance version for new buildings and energy-related renovations: The Ecolift L is the sustainable alternative where more performance is required.

Ecolift XL

The powerful version for commercial buildings, apartment buildings and rainwater:
The Ecolift XL delivers concentrated power with a power rating of up to 4.5 kW.

Installation video

Step-by-step assembly
